-6 PTFE Stainless Steel Braided Fuel Line Hose (per foot)

-6 PTFE Stainless Fuel Line has a 3/8" inside diameter and is Methanol Alcohol compatible as well as brake fluid, nitro, clutch oil, power steering, virtually anything!

PTFE is short for polytetrafluoroethylene, also known by the brand name Teflon, which was originally created by DuPont. PTFE is without doubt the ultimate hose material because of its very unique and useful properties.

It has supreme chemical resistance and will not break down even after years of use with methanol. Regular rubber (EDM or NBR, which is what almost all fuel lines are made from) begins to break down even before one year wreaking havoc on your fuel delivery system and injector nozzles. Rubber hoses can even begin to leak or spray fuel, which can be pretty dangerous.

Our PTFE hose:

• Stainless steel outer cover for excellent abrasion resistance.
• Seals the fuel in as the PTFE acts as a vapor barrier to prevent methanol or gasoline vapors (and odors) from seeping out. When methanol evaporates out of rubber hose, it is replaced with oxygen, the enemy of methanol fuel delivery systems. This corrodes the aluminum fittings and rubber hose leaving behind the harmful white powder which can clog filters and cause injectors to stick.
• Has a much higher and safer working temperature range of -94 degrees Fahrenheit to over +490 degrees.
• Features the subdued look of black nylon on the outside with a strong stainless steel liner wrapped around the PTFE inner hose.
• Is rated for really high pressures, although you'll never need it for the fuel line. This -6 hose handles 4000 PSI.
• Smooth bore for maximum flow rate

Fuel Delivery Diagram for 8 Injector

Fuel Delivery Diagram for 4 Injector
