Spindle for 600 Micro Sprint, HBS Deluxe

SKU 01-090
$99.00
1Review

Temporarily Out of Stock

Brief Description

Spindle for 600 Micro Sprint, HBS Deluxe

Details

Get the original (and the best!) HBS Deluxe 600 Sprint Front Spindle with keyway for use with our exclusive locking array nut (sold separately) which eliminates the problem of the spindle nut coming loose and allows precise loading of the bearings.

Only Hyper Racing designs, manufactures and sells this superior spindle. Others have attempted to copy it, but only Hyper Racing's spindles have all of these innovative features and specifications:

  • 10 degree king pin angle
  • 1.00" diameter 7075 T-6 snout
  • Keyway in snout for use with Hyper Racing's exclusive 01-1304 Array Nut
  • Designed to easily accept our 366-050 HBS Front Brake System
  • Replaceable bronze bushings with a custom figure 8 grease groove
  • Fits right or left side (they are the same)
  • Lightweight and strong
  • 2-1/8" center distance between 3/8" bolts for steering arm
  • 5/8" diameter 01-0921 King Pin
  • 2.080" kin pin boss height
  • C-ring groove if not using array nut
  • Made in the USA
  • Black anodizing with secondary post machining


Remember, only Hyper Racing's HBS Deluxe Spindle has the keyway or groove in the snout to allow the use of our 01-1304 Array Nut which eliminates the problem of the spindle nut coming loose and allows precise loading of the bearings.

HBS Deluxe Spindle includes two bronze bushings. Array Nut sold separately.

Weight in Pounds

0.92
